Hey there,
So I just ordered one via the link I posted a while back and even though it says “Out of Stock” it should be shipped within 2-5 days. I’ll post an update when it starts shipping and when I receive it.
Any idea if Asrock are going to release a Zen 3 bios for this board?
500 boards are supposed to be universally supported according to AMD, so I would think they would also pressure the Mainboard manufacturers into doing it. Question is just when.
Interestingly I just got my package today in the mail, ordered it on provantage awhile ago and the order status still says processing, yet here it is.
Should note the packaging from provantage was kinda lackluster, single peace of bubble wrap on top of the box, with nothing underneath or on the sides to protect it, I hope no ones orders get damaged in shipping.
4 Likes
Can you by any chance pop an APU in it and check if sound output over the HDMI port is working or if it is video-only?
Sorry, this came earlier than expected and I don’t have any cpus to throw in it at the moment.
A few things I’m unsure of with this board so far:
ECC error reporting support - presumably this needs a CPU rather than APU, would be nice once someone has one up and running to confirm if ECC functions correctly.
Any 3200 MT/s or above ECC Ram available yet? The RAM speeds seem a bit of limiting factor now that Ryzen 5000 can support faster speeds.
I found this a while ago but am not familiar with ATP, have not seen them available anywhere yet.
https://www.anandtech.com/show/15586/atps-ddr43200-industrial-dimms-up-to-128gb-12v-for-amd-intel
OS support doesn’t mention - Debian or Proxmox - anyone else thinking of using this for Proxmox?
I suppose if you need to increase the number of drive connections at some point you need to keep the bottom PCIe slot free for that and consider an external USB sound card.
Had written off this thing ever showing up, then, almost completely boot stomp the box while taking out the trash.
Will be swapping this out with a current X47D4U, 3700x, 64MB RAM, cant recall the rest. Proxmox host this week. Will try and answer any questions anyone has if I can (Don’t have an APU)
3 Likes
https://www.kingston.com/germany/en/memory/search/?partid=KSM32ES8/8ME
https://www.micron.com/products/dram-modules/udimm/part-catalog/mta9asf2g72az-3g2
Only came out very recently but the awesome thing is that these DIMMs have Micron E-Dies on them!! So they will most definitely do a stable 3200MT/s and maybe higher with ECC.
But beware there are other Kingston DIMMs that use Hynix D-Die so not all are E-Die.
1 Like
Thanks I found another thread here with the Kingston suggestion and also noticed this morning whilst looking at the product page on Asrock Rack that the ME one (KSM32ED8/32ME) is on the QVL too
Not a bad price either…
I was wondering what the significance of the similar Kingston products were as I noticed the HD and ME in the part numbers, so that also makes sense now thanks.
Can’t find anywhere yet with the non dual 10GbE variant as yet so just short listing components at the moment.
Successfully tested 2 x Micron 32 GB DDR4-3200 ECC UDIMMs with a Renoir Pro APU on an ASRock X570 Taichi at DDR4-4000 (1.35 V).
You won’t see ECC modules with >DDR4-3200 since this is the fasted standardized DDR4 frequency.
2 Likes
Just FYI. Since today the X570D4U-2L2T is in stock at Sona.
Yeah I saw that too.
I think yesterday was the official launch of the microATX 2L-2T because other retailers also have them in stock.
I’ll post another link.
Sadly I haven’t seen an indication that is has been shipped to me so I’ll post an update.
3 Likes
ASRock Rack’s support confirmed that if you use a Renoir APU you can use Video + Audio over the HDMI interface even though the motherboard itself does not have any audio device onboard.
1 Like
It will be delivered tomorrow.
1 Like
Here’s to hope.
Just something else: Don’t we want this thread to take over the X470D4U discussion thread? That one is still very active and this one doesn’t receive much love bar people like me talking/complaining about the availability. So let’s get people to notice this!
You’ve ordered at Sona too?
Well yeah that’s what I said in previous posts. I’m sorry you didn’t notice.
I ordered it last week and and haven’t received a confirmation e-Mail that it’s been shipped out to me even though it’s been “in stock” since yesterday. And calling them didn’t work as their phone line was never occupied.
That’s a pity for you. I placed the order on the 20.10.
I forgot to mention that I haven’t received a shipping note by them. It’s UPS that announced the delivery on tomorrow.
