Hi folks,
I could use some help on an eGPU problem that looks like a platform/firmware quirk on my AMD Framework 13 (7840U). The exact same dock and the same two TB4 cables work as expected on an Intel laptop, but on the Framework the eGPU path keeps negotiating PCIe Gen1 x1 at the root. That lines up with the bad performance and low board power I’m seeing in games. Both machines are running Pop!_OS 24.04 beta.
Below is everything I tried, what the system reports, and how I compared it against an Intel host. I included copy-pastes so you can see the actual evidence.
Hardware
- Laptop 1: Framework 13 AMD mainboard (Ryzen 7 7840U)
- Laptop 2: Intel Comet Lake host (ThinkPad X1 Carbon in my test)
- eGPU: AMD Radeon RX 9060 XT (PCI ID 1002:7590) in a DIY TB3/TB4-compatible GPU dock (AliExpress WKGL17 family, shows up as vendor “TB4 HOME, device TB4 eGFX”)
- Cables: two separate 40 Gbps TB4 cables tested
- External monitor connected to the eGPU outputs
- OS on both: Pop!_OS 24.04 beta
Symptoms on the AMD Framework
- Poor frame rate in multiple demanding games. GTA V was one example. No frame caps or vsync. Proton versions swapped, no change.
- GPU board power is low and fans often idle even under load.
- sclk will jump, but PCIe bandwidth appears bottlenecked.
- Hotplug hangs the system, so I cold boot to change ports.
What the AMD system reports
Thunderbolt layer looks fine
The dock shows up consistently at 40 Gbps in both directions.
$ boltctl list
● TB4 HOME TB4 eGFX
vendor: TB4 HOME
generation: Thunderbolt 3
status: authorized
rx speed: 40 Gb/s = 2 lanes * 20 Gb/s
tx speed: 40 Gb/s = 2 lanes * 20 Gb/s
Thunderbolt sysfs also matches:
/sys/bus/thunderbolt/devices/0-2/vendor_name:TB4 HOME
/sys/bus/thunderbolt/devices/0-2/device_name:TB4 eGFX
/sys/bus/thunderbolt/devices/0-2/device:0x2
GPU is present and mapped to the TB chain
$ lspci -nn -s 07:00.0 -vv | sed -n '1,2p'
07:00.0 VGA compatible controller [0300]: Advanced Micro Devices, Inc. [AMD/ATI] Device [1002:7590] (rev c0)
Subsystem: Sapphire Technology Limited [1da2:a493]
Full PCIe path as shown by lspci -t on the AMD host:
-[0000:00]---03.1-[03-61]----00.0-[04-61]----01.0-[05-61]----00.0-[06-07]----00.0-[07]----00.0
That means the upstream root for this branch is 00:03.1.
The bottleneck at the root port on AMD
00:03.1 always shows Gen1 x1 when the eGPU is attached there:
$ sudo lspci -s 00:03.1 -vv | grep -E 'LnkCap|LnkSta'
LnkCap: Port #247, Speed 2.5GT/s, Width x1
LnkSta: Speed 2.5GT/s, Width x1
I also saw the dock occasionally land under 00:04.1, which is the same story:
$ sudo lspci -s 00:04.1 -vv | grep -E 'LnkCap|LnkSta'
LnkCap: Port #0, Speed 2.5GT/s, Width x1
LnkSta: Speed 2.5GT/s, Width x1
There are good root ports in this machine, for example 00:02.4 reports Gen4 x4 capability and usually negotiates Gen3 or Gen4, but my TB chain never ends up under that one with this dock:
$ sudo lspci -s 00:02.4 -vv | grep -E 'LnkCap|LnkSta'
LnkCap: Port #0, Speed 16GT/s, Width x4
LnkSta: Speed 8GT/s, Width x4 # when something else is hung off it
So the TB path that contains the eGPU keeps getting routed to the “slow” root complex function.
GPU power and activity on AMD
ROCm SMI confirms low power when the link is bad. A couple of representative snapshots:
Idle or light load:
"Average Graphics Package Power (W)": "26.0"
"pcie_link_width (Lanes)": "4"
"pcie_link_speed (0.1 GT/s)": "80"
"GPU use (%)": "11"
In GTA V, still not pulling anywhere near PPT and frames are unstable:
"Average Graphics Package Power (W)": "70.0"
"Voltage (mV)": "861"
I also tried:
- forcing performance level
- max PPT via
power1_capwhere available - checking
pp_power_profile_modeandgpu_metrics
Ports/reboot/cables
- Tried both rear USB4 ports on the Framework (these are the only USB4 ones for this board)
- Two separate TB4 cables
- Cold boot for dock and laptop each time
- Hotplug is unstable on this host, so avoided
Result is consistent. The eGPU branch heads under 00:03.1 or 00:04.1 and negotiates 2.5 GT/s x1.
Comparison on the Intel laptop
Same dock and cables. Same OS version. Here the path is clean and bandwidth is what we want.
Find the GPU and show the PCIe tree
$ EGPU=0000:32:00.0
$ lspci -t -s ${EGPU#0000:}
-[0000:00]---1d.4-[05-52]----00.0-[06-52]----04.0-[2e-52]----00.0-[2f-52]----01.0-[30-52]----00.0-[31-32]----00.0-[32]----00.0
Upstream root here is 00:1d.0 or 00:1d.4 depending on the bridge view.
Root port link on Intel is correct:
$ sudo lspci -s 00:1d.0 -vv | grep -E 'LnkCap|LnkSta'
LnkCap: Speed 8GT/s, Width x4
LnkSta: Speed 8GT/s, Width x4
sysfs:
/sys/bus/pci/devices/0000:00:1d.0/current_link_speed = 8.0 GT/s PCIe
/sys/bus/pci/devices/0000:00:1d.0/current_link_width = 4
Thunderbolt bridges on the Intel chain
The bridge that actually carries the GPU tunnel reports Gen3 x4:
$ sudo lspci -s 2f:01.0 -vv | grep -E 'LnkCap|LnkSta'
LnkCap: Port #1, Speed 8GT/s, Width x4
LnkSta: Speed 8GT/s, Width x4
Another adjacent TB hop shows 2.5 GT/s x4 on paper, but that is not the hop used by the GPU tunnel i think is a common Alpine Ridge quirk? The important one is the one above which is 8.0 x4.
Internal AMD switch on the card
As expected:
Parent 31:00.0: LnkSta: Speed 32GT/s, Width x16
GPU 32:00.0: LnkSta: Speed 32GT/s, Width x16
Thunderbolt identification on Intel
$ boltctl list
● TB4 HOME TB4 eGFX
vendor: TB4 HOME
generation: Thunderbolt 3
rx/tx: 40 Gb/s each way
What I tried on AMD that did not resolve it
- Switched between both rear USB4 ports
- Two separate 40 Gbps TB4 cables
- Cold boot sequences for both dock and laptop
- Updated BIOS and firmware to latest available
- Kernel driver stack as shipped with Pop!_OS 24.04 beta
- Forced perf level, power caps, profiles
- Verified external monitor is cabled to the eGPU
- Proton versions for games to rule out Wine quirks
None of that moved the upstream root negotiation off 2.5 GT/s x1.
Dock chipset identification
The dock introduces Intel Thunderbolt 3 bridges. On AMD I saw:
03:00.0 / 04:01.0: Intel DSL6340 Thunderbolt 3 Bridge [8086:1576]
On Intel I saw Alpine Ridge 4C in front of the 2C bridges:
05:00.0 .. 06:04.0: Intel JHL6540 Thunderbolt 3 Bridge [8086:15d3]
2e:00.0 / 2f:01.0: Intel DSL6340 Thunderbolt 3 Bridge [8086:1576]
So the enclosure is using Intel Alpine Ridge silicon, which is fine for TB3 eGPU. The TB layer shows 40 Gb/s. That aligns with the good results on the Intel host.
Commands I used to identify it:
for d in /sys/bus/thunderbolt/devices/*; do
echo "== $(basename "$d") ==";
grep -H . $d/{vendor_name,device_name,device,device_revision,unique_id} 2>/dev/null
done
for b in 03:00.0 04:01.0 2e:00.0 2f:01.0; do
sudo lspci -nn -s $b -vv | sed -n '1,3p'
done
Where I think the bug is
- The dock and both TB4 cables are good. Verified on an Intel laptop where the GPU path is PCIe Gen3 x4 end to end and everything looks normal.
- On the Framework 7840U, the eGPU branch keeps landing under
00:03.1or00:04.1which only support or only negotiate 2.5 GT/s x1. That matches the poor real-world performance and low power draw. - There are good root ports on this machine that can do Gen3 or Gen4 x4 (
00:02.4,00:08.x), but the eGPU chain is not routed there.
This feels like a routing or capability exposure problem in firmware or the USB4/TB stack on the AMD platform, not a GPU or dock fault?
If anyone can confirm any of the following:
- Anyone in the Framework/AMD usebase: is there a known issue with USB4 routing or root port assignment on the 7840U board that pushes eGPU tunnels under
00:03.1or00:04.1at Gen1 x1? i dont think eGPUs are officially supported on the 7040 series motherboards, but there are many examples of people using eGPUs in the wild, and USB4 should? be compatible with these tb docks? - Any firmware settings, NVRAM knobs, or kernel parameters that force the TB eGPU path to a Gen3 x4 root port like
00:02.4? - If someone has a similar AMD Framework setup with a TB eGPU working at Gen3 x4, I’d love to see your
lspci -tand theLnkStalines for your root port and TB bridges
steps to reproduce:
On the host that is misbehaving:
EGPU=$(lspci -Dn -d 1002:7590 | awk '{print $1; exit}')
echo "EGPU=$EGPU"
lspci -t -s ${EGPU#0000:}
ROOT=$(readlink -f /sys/bus/pci/devices/$EGPU | tr '/' '\n' | grep -E '^0000:' | head -n1)
echo "ROOT=$ROOT"
sudo lspci -s ${ROOT#0000:} -vv | grep -E 'LnkCap:|LnkSta:'
for b in 2e:00.0 2f:01.0 03:00.0 04:01.0; do
sudo lspci -s $b -vv | grep -E 'LnkSta:' || true
done
boltctl list
On a known good host, the same set should read 8.0 GT/s x4 at the root and on the active TB hop.
Happy to run more tests if anyone has any ideas. Thanks in advance for any thoughts on getting this eGPU off of the slow 2.5 GT/s x1 root on the AMD Framework.
