Post your 3D-Drawings

CrossCarbon · December 16, 2016, 9:15pm

As some in this community might be familiar with one or the other CAD programm, I figured we might want to share our best, worst or first creations.
To prevent confusion:
It does not have to be AutoCAD. LegoDigitalDesigner, Giants Editior, 123D Design, Fritzing, Pencil drawing, YOU name it! Post it!

So here we go! Design away!

kewldude007 · December 16, 2016, 9:17pm

Positron · December 16, 2016, 9:23pm

I can't afford a 3D printer so I made my own. (printed on the Formlabs Form 1+)

Full disclosure:
I cheated a little bit by starting with a public domain CAD file. In order to shrink it for 3D printing, I had to greatly reduce the details and parts count (nuts, bolts, etc.). Then I fattened up some parts so they could be printed. No shop could print it except for the guys with the Form 1+.

Tiny 110mm Kossel 3D printer model by protosynthethos on Sketchfab

Positron · December 16, 2016, 9:25pm

Tork 1:18 scale R/C truck wheel by protosynthethos on Sketchfab

Positron · December 16, 2016, 9:31pm

For the canopy I used a observation bubble from a PBY Catalina R/C airplane.

Jetsons by protosynthethos on Sketchfab

Positron · December 16, 2016, 9:40pm

My Masters thesis was modeling and performing a finite element structural analysis on the frame of the Lotus 7 sports car.

Lotus Frame by protosynthethos on Sketchfab

eidolonFIRE · December 16, 2016, 11:59pm

I did some stuff in blender back in highschool...

kewldude007 · December 17, 2016, 1:40am

Finally a real drawing for this rubber ring, specifically a punch to make them

shit I forgot a dimension

overall thickness is .5 inch

anon94261841 · December 17, 2016, 2:18am

Nothing too crazy

Back panel to use RCA on an ODAC

NZXT S340 power button for use with Omron B3F-10XX switches

Beyer by meri DT 990 earcups

"PiGrrl" custom enclosure. Too large to print on my printer :( 99.3% sure I'll be redoing it.

cotton · December 17, 2016, 2:19am

  _______________
 |\              |\
 |  \____________|__\
 |   |           |   |
 |___|___________|   |
  \  |            \  |
    \|______________\|

CrossCarbon · December 17, 2016, 2:33am

Lego Digital Designer is also CAD, isn´t it?

cotton · December 17, 2016, 2:35am

I failed to read the OP - where it said CAD. I just read the title and felt I could contribute.

Apologies for derailing your thread.

CrossCarbon · December 17, 2016, 2:36am

You did that thing on a computer, did you?
And the computer aided you.
And you designed something
Computer Aided Design happend!
Updated OP

Shmidershmax · December 17, 2016, 2:45am

I've only dabbled in 3d art. I wish a had the patience to stick with it.

Positron · December 17, 2016, 3:35am

Way back in the 90's when I was using AutoCAD at work, I came up with an idea for a game I called LegoCAD.

Then Notch invented Minecraft.

Positron · December 17, 2016, 3:04pm

ftfy @CrossCarbon

Added the tail

Level1Techs wallhanger V2 by protosynthethos on Sketchfab

I realized your version would not print that well being a 20mm thick solid block.
.

Level 1 Techs wallhanger v3 by protosynthethos on Sketchfab

Hollowed out shell for 3D printing. Will 3-4mm thick work @kewldude007 ?

Zavar · December 17, 2016, 3:17pm

Got a couple of simple solidworks models on grabcad.

https://grabcad.com/jasper.crowe-1/projects

Currently using 3DS Max to do modelling where I'm working now. Making a house to practice. I'll do a quick render on Monday.

kewldude007 · December 17, 2016, 3:38pm

yes

CrossCarbon · December 17, 2016, 4:06pm

Yeah well, that is the difference between CNC mills and 3D Printers.

Positron · December 17, 2016, 4:12pm

Well... now we have models suitable for both additive and subtractive mfg.
