Capture 4k 60 fps or 4x 1080p 60fps and compressing

I need to record video from 4 1920x1080 60fps USB 3.0 cameras. They output in YUY2 (same as YUYV on Linux I believe) and so to save space I need to store them in h264, h265 or AV1. So it’s different than just having a video file, YUY2 is waay to big to store.

I have tried to figure out what sort of performance I need to achieve this (other than the USB bandwidth) and have gotten nowhere. I want a mobile solution so been looking at raspberry and n100 to power off a power bank. I am now looking at laptops and yet I have no Idea how to figure out what I need to do this.

with h265?

OBS and a modern GPU

1 Like

H265 for example. What sort of modern GPU is then needed to encode these streams? are we talking an iGPU, a mobile 1050 or an H100?

did you look in to ffmpeg ?
https://trac.ffmpeg.org/wiki/Capture/Webcam

i read a post this one time, I can’t find it, he did 7 1080 streams on a n100.

encoding 1080 on a pi works but it pushes it.

its released somewhere 2013. look of at the specs on the hardware if they have encoder

If i look to my 6 year old i5 laptop. 16 gb ram. nvidia none rtx videocard i thought . That computer wouldn’t brake a sweat doing that.

Search for some laptop, best to have not like 2 usb ports. Nvidia graphics. You want all the encoders you can get. And doing this on battery’s will drain the shit out of the battery’s. If you also want battery life. Then look at the m macs

The two laptops I am aware that had 4 USB-A ports are discontinued.
Most have 2 or 3 Type-A and 1 to 4 Type-C

Very many devices are capable of 10Gbit/s total over USB, if I need hubs then it’s not a big issue.

I have gotten somewhere with the USB bandwidth issue, it’s not really much of one, just a box that needs to be checked.

Encoding the video streams I have no clue about. Except what’s overkill gonna get it done.

I think I’ll try to look more into N100 or N200 then. Also comparing their iGPU to framework offerings for the mobo with 3d printable cases. I’m a little scared it might be a bit hot and noisy though it could also be. There are other options like the PN51-S1 that can be powered from a battery bank but battery life is something to consider for sure.

Still, wish there was some easy look up or math I could do to estimate what I need. Seems it’s either crawl the web for someone who did the thing before or just try and see.

1 Like

To have one answer to the math its not there because you can have difrent levels of quality. what inpacts the enoding time hugely.

If its need to be mobile go mobile. A i5 would be way better.

Try searching through this guy’s stuff.
