MinisForum BD795i SE - m.2 e-key pcie lanes

[Destari]

Does anyone who owns a BD795i SE know if the m.2 e-key slot provides 2x pcie lanes or only one? It seems like most manufacturers save the money and don’t implement the full spec, only providing 1x pcie lane to the slot.

I am trying to build out a new home automation box and want to incorporate a Google Coral TPU, specifically an onboard one, because the usb devices are not well supported by proxmox in my experience. I was hoping to get a dual TPU module that fits an e-key wifi-card slot but it looks like it requires both pcie lanes to be provided.

Similar forum post here:

M.2 E-Key Adapters

Do M.2 E-Key adapters or PCIe to M.2 E-Key adapters that fully implement the spec actually exist? Per the Google Coral Dual TPU product page Although the M.2 Specification (section 5.1.2) declares E-key sockets provide two instances of PCIe x1, most manufacturers provide only one. To use both Edge TPUs, be sure your socket connects both instance…

Thanks in advance.
