A-arch?
Do YOU want to be a semi neck beard and impress your somewhat neckish friends but don’t want to install gentoo and be a /g/tard? Arch is your new best friend.
omg… FOR FUCKS SAKE ANOTHER ARCH INSTALL GUIDE! No, no, no, this one is a little different, its more of a collaboration of things and I will be running through a complete install guide up to the point where you will be playing your favourite games natively in wine. And moreso the point of this is so you don’t end up running into a multitude of issues like crashing your computer ever time you run Xorg because for some reason you really messed up your graphics card drivers. Even if you are super newfag than you should be able to understand this guide.
This will be a 64 bit install.
Also note: I did all of this on my laptop which was not running arch at the time, so everything below is from memory. Please correct me on any typo’s I may have wrote or if I have missed anything.
Also I got sick and tired of seeing a WIP sitting on my desktop so I have just posted this incomplete. I will add shit to it when I get time. Hopefully there is enough here to get you pretty well settup.Setting up the drives
I am going to assume that you are using a blank wiped hard drive and we are going to set everything up, including the partition table, from scratch.
Noobs be warned. Your data will be WIPED
Download your Arch Linux iso. You can find the download here.(insert link)
Making a bootable usb in Linux
Find where the download is located and have the path on hand. Now we are going to have to find out what the pathname is to the USB, i.e. where its mounted. The easiest way to do that is to check all of the currently inserted devices, then plug in your usb and check again. The new device is your usb, have this path on hand as well.
fdisk -l
You can see all of the drives connected using fdisk
sudo dd if=/path/to/file.iso of=/path/to/usb bs=1m
Run this command and replace the pathnames where applicable. If you are getting errors back saying something along the lines of invalid size or something just change bs=1m to bs=1M and that should fix it.
Making a bootable usb in OSX
Pretty much the same process as linux so I just copied what I have already written. The only difference is finding what devices are currently connected.
Find where the download is located and have the path on hand. Now we are going to have to find out what the pathname is to the USB, i.e. where its mounted. The easiest way to do that is to check all of the currently inserted devices, then plug in your usb and check again. The new device is your usb, have this path on hand as well.
diskutil list
This just lists all the connected devices. Run it make a note of everything that is currently connected and then plug in your usb and run it again to get the pathname. Protip: if you want to skip typing in the file name for iso you can just drag in the iso into the terminal and it will copy the pathname over.
sudo dd if=/path/to/file.iso of=/path/to/usb bs=1m
Run this command and replace the pathnames where applicable. If you are getting errors back saying something along the lines of invalid size or something just change bs=1m to bs=1M and that should fix it.
Making a bootable usb in Windows
Thanks to @Willdrick for the links
Great! You now have a bootable arch usb. Because of the variation in motherboards and booting stuff etc… I’m just going to assume that you can figure out how to boot off it. But once you are booted off it thane will be faced with the selection screen. We are going to choose the 64-bit version.
Making the partition tables and installing base arch
We are going to want to look at the current partition table on the hard drive. I am assuming you only have one hard drive connected to the motherboard. (N.B. You can find out what is connected using fdisk -l)
fdisk /dev/sda
Now if you want to see the current partitions of the drive you can use p
p
Because we are doing a completely clean install we are going to write a new DOS partition table.
o
Now everything is clean, lets make the partitions. Make a new partition, this is the swap
n
Its going to be a primary partition
p
Its going to be the first partition on the table
1
Now we are going to hit enter again because we want it to start at the beginning of the hard drive, and its going to be around 2 gigs, so we type in
+2G
We are going to select the type for that by hitting t
t
Select the partition number which should be 1
1
And now type in 82 which is the Linux Swap type for the partition.
82
We make a new partition
n
Its going to be primary again
p
Its going to be the second partition on the table so just hit enter and that should default to 2. We hit enter twice and that will default to take up the rest of the space on the hard drive. You can/should be splitting up your partitions for /var/ and /boot/ etc… but today for simplicity’s sake we are going to just put it all in the same partition.
Make that partition bootable
a
And select the partition number which should be 2
2
We hit w and write that to the disk
w
We make the swap
mkswap /dev/sda1
Turn on the swap
swapon /dev/sda1
Format the primary partition
mkfs.ext4 /dev/sda2
We mount the partition to a pre-existing directory
mount /dev/sda2 /mnt
Make a few directories that we will need later
mkdir /mnt/boot
mkdir /mnt/home
We are going to install arch but we are going to need internet for that. If you have a wireless card than you should be able to connect to it automatically with wifi-menu but in the case that you can’t than have a look through the arch wiki for a fix. In any case try one of the below methods.
Network Config Link:
https://wiki.archlinux.org/index.php/Network_configuration
Wired:
If you have a wired connection it should already be automatically connected but we will still need to enable it to start automatically on reboot.
ip link
This should give you back something that looks like this
ip link
1: lo: mtu 65536 qdisc noqueue state UNKNOWN mode DEFAULT group default
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
2: enp4s0: mtu 1500 qdisc pfifo_fast state UP mode DEFAULT group default qlen 1000
link/ether ##:##:##:##:##:## brd ff:ff:ff:ff:ff:ff
Now we want the second option which should be something along the lines of enp#x# which is the LAN adapter. Run the following command
systemctl enable dhcpcd@eth4s0
Replacing eth4s0 with whatever your code was.
Wifi:
Install some packages using pacman and run wifi menu to connect to the network
wifi-menu
pacman -S wireless_tools dialog wpa_supplicant wpa_actiond
Enable the service
systemctl enable net-auto-wireless
If you have got internet than you can check your connection by just pinging a google server.
ping -c 3 google.com
If you do don’t have an internet connection you can see the section on wifi below for different methods
If you have internet you should be getting some data back. From here on I’m going to assume that you have a internet connection. Now we are going to pacstrap this mother fucker, I include base-devel cause I’m not a fucking weird cunt that doesn’t use sudo and disconnects his computer from the internet to use su. Really base-devel has a lot of useful stuff
pacstrap /mnt base base-devel
Now go and take a shit or a sleep for a while cause this aint going to be a quick process. Once that’s done generate the fstab
genfstab -p /mnt >> /mnt/etc/fstab
We are going to chroot into the mnt
arch-chroot /mnt
Set the hostname (just replace jfing-pc with whatever you want to call it)
echo jfing-pc > /etc/hostname
Now we are going to set the local timezone. Ideally choose the place closest to your physical location. Being an Ausfag mine is /Australia/Brisbane but you can list all of them using
timedatectl list-timezones
Or you can jump on this URL to get a list of all of them. https://www.archlinux.org/packages/core/any/tzdata/files/
Enter the applicable location
cp /usr/share/zoneinfo/Australia/Brisbane /etc/localtime
Generate the locale.
locale-gen
Set the clock
hwclock —systohc —utc
mkinitcpio -p linux
Make a password
passwd
Enter your password
And setup a boot loader, I’m just going to go with grub but some people like gummiboot or whatever floats your goat. Personally those are the same people who use zish instead of bash and ssh in through 10 proxies and VPN to log in because they are afraid that someone will steal their precious javascript calculator code that can return true for 0.1 + 0.2 == 0.3 Anyway we are going to install grub with pacman
pacman -S grub
Hit y and enter to continue with the install. Once that is installed we are going to install grub to the system being used
grub-install /dev/sda
Make the configuration file
grub-mkconfig -o /boot/grub/grub.cfg
exit
Unmount everything and reboot
umount -R /mnt
reboot
Congradufuckinglations. You just installed arch \m/
Setting up your basics
Log in as root and enter your password. We will make a new user in a little bit but while we are setting up the basic stuff that goes on in the background we are just going to stay in root for the minute.
Using Android phone as a hotspot for internet
https://wiki.archlinux.org/index.php/Network_configuration
You should already have this working but in the case that you don’t.
Now it is a common misconception, especially amongst wifi users, that if you did not install the wifi drivers, than you will not be able to connect to the internet and will have to do a reinstall or connect via ethernet to download said drivers. BUT. I have a fix. If you have an android phone (I haven’t tried a iPhone or windows phone) that can be tethered through USB, you can use it as a wifi modem. We will have to connect to it manually. I will run through that now.
USB tethering with android phone:
ip link
Before you plug it in run this command to show all the currently connected networking interfaces. You might have one, none or a few. It doesn’t matter. Now plug in your device, turn on USB tethering and run ip link again and you should have a new device come up. It should look something like the last one on the list.
ip link
1: lo: mtu 65536 qdisc noqueue state UNKNOWN mode DEFAULT group default
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
2: enp4s0: mtu 1500 qdisc pfifo_fast state UP mode DEFAULT group default qlen 1000
link/ether ##:##:##:##:##:## brd ff:ff:ff:ff:ff:ff
3: wlp2s0: mtu 1500 qdisc mq state DOWN mode DEFAULT group default qlen 1000
link/ether ##:##:##:##:##:## brd ff:ff:ff:ff:ff:ff
5: enp0s20u3: mtu 1500 qdisc noop state DOWN mode DEFAULT group default qlen 1000
link/ether ##:##:##:##:##:## brd ff:ff:ff:ff:ff:ff
Now you want this number
enp0s20u3f
Connect to it like this
dhcpcd enp0s203f
And it should work. Just ping it to see if you have a connection. You should be able to connect to your wifi or mobile data or whatever.
Configuring pacman
Oh shit… I will admit that when I wrote this guide, I left this part to the end. Fucking pacman, I love it and hate it at the same time. As a package manager its amazing. I love it. But setting it up properly is a cunt. The first time I used arch I fucked up my server list and spent an hour fixing it. Was not pretty. That day I reinstalled arch over 5 times. Anyway, I digress, setting up pacman. I’m going to write a bit on this subject because its quite important.
Pacman has a list of mirrors that it relays to, to get the packages. Although not ever server has all of the packages. So what it does is tries to download a package from the first server in the list and if the server doesn’t have the package it tries the next one and so on. The first server on the list of mirrors is not the closest one so we will have to set that up and its pretty nice to set up powerpill as well as it gives you parallel downloads, greatly speeding things up. I will talk about that as well a little further down, although that can be a bit wonky and sometimes doesn’t work for any particular reason. If, like me, you had powerpill mess up over and over again than you will want to just use pacman and so its important to optimise that.
Refreshing keys and optimising pacman's database indexing
Thanks to @kiipa for reminiding me about refreshing keys and pacman-optimize. It makes for a little faster searching and downloading of packages
pacman-optimize && pacman-key --init && pacman-key --populate archlinux
Optimising the mirror list
So when you first install arch its a little weird and doesn’t come with the right server list. Its just a jumble of servers chucked in and none of it is organised (well I’ve found this to be the case for some versions but not others). So lets get a fresh copy of that server list
pacman -S wget
Download wget
wget -O /etc/pacman.d/mirrorlist https://www.archlinux.org/mirrorlist/all/
This will just write over the top of the previous mirror list with the new one from the website. Its now nice and organised with the mirrors sorted into the ones from their own country.
The easiest way to now rank all the mirrors is to use a bash script called rankmirrors. So we want to backup the previous mirror list to edit it
cp /etc/pacman.d/mirrorlist /etc/oacman.d/mirrorlist.backup
Even if you fuck up somehow you can just redownload the mirror list with the wget command before. That will just write over the list with all the mirrors. Now I’m going to assume that you know how to use nano, I really don’t feel like doing a write up on it so have a look at it on the web somewhere. But when you are in nano you want to uncomment all the servers in your country and the world wide servers (the world wide servers have all of the packages just in case for some reason your country doesn’t have all the packages). When I say uncomment I mean just remove the # that is in front of the line. For instance
.#Server = http://mirror.aarnet.edu.au/pub/archlinux/$repo/os/$arch
For some reason it won't let me just have the hash there. The dot is not meant to be there
is commented and therefore isn’t acknowledged when pacman reads the mirror list, when compared to
Server = http://mirror.aarnet.edu.au/pub/archlinux/$repo/os/$arch
in which case pacman will use the server as a mirror. You can nano in like this
nano /etc/pacman.d/mirrorlist.backup
Now that you have only your country and the worldwide servers uncommented we are going to rank them by speed. This just basically pings them and gets a speed back and ranks the servers based upon the best results.
rankmirrors /etc/pacman.d/mirrorlist.backup > /etc/pacman.d/mirrorlist
Yay. Your mirrors are ranked and the download speed should be OVER 9000. Now we are going to have uncomment some things in the paceman.conf file so that we can get access to the 64 bit downloads and libraries. This is very important otherwise we are not going to be able to get all the support for the 64 bit drivers and then we will get crashes.
nano /etc/pacman.conf
You are going to want to have multilib, extra, community and core all uncommented
[core]
SigLevel = PackageRequired
Include = /etc/pacman.d/mirrorlist[extra]
SigLevel = PackageRequired
Include = /etc/pacman.d/mirrorlist[community]
SigLevel = PackageRequired
Include = /etc/pacman.d/mirrorlist[multilib]
SigLevel = PackageRequired
Include = /etc/pacman.d/mirrorlist
It should look like this. Refresh the package list
pacman -Sy
This will update pacman.
Pacman’s functions
Adding a package
pacman -S packagename
Removing a package
pacman -Rns packagename
Updating all the packages in the system
pacman -Syu
Querying the currently installed packages
pacman -Qs packagename
Searching the repos for a package
pacman -Ss packagename
If you want a bit more info on a specific package whether installed or on the repos you can just add a i
pacman -Qi packagename
pacman -Si packagename
Users
Users are very important for security reasons but you can read more of that else where on the internet and I’m going to save some time and just show you how to set it up.
useradd -m -g users -G wheel,storage,power -s /bin/bash jfing
passwd jfing
Now you replace jfing with whatever you want to call your username and you enter your password once prompted
As we installed base-devel we already will have sudo so we just need to edit in our user name so we can use sudo commands. We are going to use nano which is a terminal based text editor.
Yaourt
You will not be able to do this section or powerpill in root as root does not allow you to make packages. You must do this under a lower tier account. Do not run makepkg as sudo.
Yaourt is an easy way of accessing the goodies in the AUR. Its relatively easy to install although you have to compile it from source.
mkdir ~/builds
cd ~/builds
wget http://mir.archlinux.fr/~tuxce/releases/package-query/package-query-1.6.2.tar.gz
tar -xvf package-query.tar.gz
cd package-query
makepkg -s
pacman -U package-query*.pkg.tar.xz
cd ~/builds
wget http://mir.archlinux.fr/~tuxce/releases/yaourt/yaourt-1.6.tar.gz
tar -xvf yaourt.tar.gz
cd yaourt
makepkg -s
pacman -U yaourt*.pkg.tar.xz
yaourt -Syyu
When using yaourt do not put sudo infront.
Updating the Package list
yaourt -Syyu
Updating all of the system packages
yaourt -Syua
Installing Packages
yaourt packagename
And thats pretty much it. Man the fuck outta that shit if you don’t know what to do or check out the wiki.
Powerpill
Powerpill is great for big downloads such as graphics drivers or bigger DE’s like gnome. You will need to have yaourt installed to get the package from the AUR otherwise you are compiling it from source and thats a bitch. There is something wrong with Xyne’s repo and it doesn’t like my signature files no matter what I did. I just couldn’t get it to fingerprint the download. But install it like this
yaourt powerpill
Now use it exactly like pacman
pacman -S packagename
becomes
powerpill -S packagename
etc..
Video Drivers and GUI’s
You are going to want a bit of a GUI, so for that we are going to need to install Xorg and the relevant video drivers for your GPU. You should know what GPU you have and if you don’t than I am surprised that you made it this far.
Drivers
PLEASE READ:
Many things, especially Xorg and some DE’s rely heavily on the symlinks to drivers and their libraries. As such when uninstalling drivers, ESPECIALLY PROPRIETARY ONES, really really breaks your system and you may as well do a full reinstall. Pick your drivers carefully. Its much easier to hop between open source than it is for closed source.
While it has been pointed out to me that uninstalling drivers shouldn't break anything, from my personal experience, I've seen many people break their system through this. For this reason I have left out an uninstall guide. If you wish to uninstall drivers I'd strongly recommend visiting the arch wiki and searching for your respective drivers.
Most of the open source drivers are very similar when it comes to their roots (for instance the ati drivers are just chopped up vesa ones) and thus mostly rely on the same libraries, specifically mesa. This makes it easier to swap them out if you do a lot of that. Although the open source ones lack the performance of the proprietary ones so its up to you choose. Alternatively if you don’t really care about GPU performance you can install the vesa drivers which will work with just about anything flawlessly.
It is up to you to figure out how to uninstall them if something goes wrong.
Also, these are only for the newer cards. i.e. Anything post 400 series for Nvidia and anything 6000 series plus for ATI/AMD
Open Source
Nvidia
pacman -S xf86-video-nouveau mesa-libgl lib32-mesa-libgl
AMD:
pacman -S xf86-video-ati mesa-libgl lib32-mesa-libgl
Intel
pacman -S xf86-video-intel lib32-mesa-libgl
Proprietary
Nvidia:
pacman -S nvidia nvidia-libgl ; reboot -h now
AMD/ATI:
Currently there are some issues with linux kernel 4 and as such I will not give a full guide on installing these drivers as
a. They are not within the official arch repository and such aren’t guaranteed to work
b. I personally have not been able to get them working with the current version of linux
Here is the wiki on them, you are welcome to try to get them to work yourself and I would appreciate it if you post your results.
https://wiki.archlinux.org/index.php/AMD_Catalyst
Xorg
Install this AFTER you install your graphical drivers
Xorg is the display driver which is necessary for a DE or WM that isn’t in the terminal. You can install it with pacman, I chucked in other packages that are essential to having a functional DE
pacman -S xorg xorg-server xorg-server-utils xorg-apps
Browsers
Firefox
pacman -S firefox
Chromium
pacman -S chromium
Opera
pacman -S opera
JRE
The dev kit pulls the runtime as well and all associated dependancies so this should be all you need to get up and going with the latest version
pacman -S jdk8-openjdk
Browser Plugins
You will want to install some browser plugging to make things functional
Flash
pacman -S flashplugin
Java
pacman -S icedtea-web
Other browser plugins
There are many more plugins available through the AUR although you will need to add the repo’s for them. They are things like pipelight which is basically silverlight for linux, google hangouts extension which is under google-talkplugin and other things. You can see more on that here https://wiki.archlinux.org/index.php/Browser_plugins If you installed yaourt than you should be able to install them no worries.
Sound
Sound drivers are handled by alsa, install them like this
pacman -S alsa-utils lib32-alsa-lib lib32-alsa-plugins lib32-libpulse lib32-openal pulseaudio-alsa pulseaudio libpulse
It's also wise to install some codecs for use of audio playback. Gstreamer is probably the best although there are other alternatives.
pacman -S gstreamer gst-libav gst-plugins-bad gst-plugins-base gst-plugins-base-libs gst-plugins-good
This should get you setup with what you need. Bad aren't necessarily bad, they just aren't up to scratch documentation wise. I've never had any issue with them. Visit the arch wiki for more info on codecs if need be and install what you need. I've provided below a list of what I have on my system. You may need legacy support for some applications.
https://wiki.archlinux.org/index.php/Codecs
https://wiki.archlinux.org/index.php/GStreamer
gst-editing-services 1.4.0-1
gst-libav 1.4.5-1
gst-plugins-bad 1.4.5-4
gst-plugins-base 1.4.5-1
gst-plugins-base-libs 1.4.5-1
gst-plugins-good 1.4.5-3
gst-plugins-ugly 1.4.5-2
gst-python 1.4.0-3
gstreamer 1.4.5-1
gstreamer-vaapi 0.5.10-1
gstreamer0.10 0.10.36-4
gstreamer0.10-bad 0.10.23-10
gstreamer0.10-bad-plugins 0.10.23-10
gstreamer0.10-base 0.10.36-3
gstreamer0.10-base-plugins 0.10.36-3
gstreamer0.10-ffmpeg 0.10.13-2
gstreamer0.10-good 0.10.31-8
gstreamer0.10-good-plugins 0.10.31-8
gstreamer0.10-mm 0.10.11-1
gstreamer0.10-python 0.10.22-2
gstreamer0.10-ugly 0.10.19-14
gstreamer0.10-ugly-plugins 0.10.19-14
gstreamermm 1.4.3-1
Run alsamixer to set them up.
alsamixer
Test that its working with this
speaker-test -c 2
There is extensive support for these on the wiki if you are having issues
Trackpad Support
Drivers for the trackpad. Pretty simple
pacman -S xf86-input-synaptics
Desktop Environments and Window managers
DE:
https://wiki.archlinux.org/index.php/Desktop_environment
DM:
https://wiki.archlinux.org/index.php/Display_manager
I will add some guidance below on getting them working specifically for arch and setting up desktop managers below. As DE’s are different to each other and to list instructions for all of them would be ridiculous, I’m just going to give a guide for installing XFCE and LXDM together, check out the wiki’s for more info on the other desktops.
Note: It is best to sudo install this as the main user account rather than root as it sets things up a little better, you can still use it as any user but you have to edit a file or two. Go and have a look at the wiki if you want the guide on LXDE install as root.
Desktop Environment - XFCE
https://wiki.archlinux.org/index.php/Xfce
We install all of the dependancies and features.
pacman -S xfce4 xfce4-goodies gstreamer0.10-good-plugin
Now we want to setup Xorg to use XFCE as the DE
echo exec startxfce4 > ~/.xinitrc
Desktop Manager
https://wiki.archlinux.org/index.php/LXDM
Install LXDM
pacman -S lxdm librsvg
Set it to start on boot
systemctl enable lxdm
To set XFCE as the default session, nano into the conf file
nano ~/etc/lxdm/lxdm.conf
And change whichever line is session to start xfce, it should look like this
session=/usr/bin/startxfce4
And now you have a desktop manager. We can also install lxdm-themes with yaourt to add a bit more personalisation. Have a look about on the net for further details on theming.
yaourt lxdm-themes
Compiz and animations
Are you ricer as fuck and like your sick 3D window management? Well I’m a minimalist so I don’t have that shit but you just install it with yaourt and set it up. There are guides on the arch wiki. If someone wants to write one up for here, stick it in the comments section and I will edit it in.
Fonts
Fonts:
https://wiki.archlinux.org/index.php/Fonts
Very important to have all your fonts, especially for wine. There are more fonts than you will probably need here but it doesn't hurt to have a lot. If you install these than you shouldn't have any compatibility issues unless there is some edge case scenario
pacman -S ttf-dejavu ttf-liberation adobe-source-han-sans-otc-fonts ttf-freefont ttf-arphic-uming ttf-baekmuk ttf-droid ; yaourt ttf-ms-fonts ttf-vista-fonts
I quite like terminus for my terminal, chuck it in there if you want... or don't.
pacman -S terminus-font
WINE, Steam and Gaming
Plenty of messing about, breaking things and fixing them again.
Native Steam
General Gaming:
https://wiki.archlinux.org/index.php/Gaming
Steam:
https://wiki.archlinux.org/index.php/Steam
Linux gaming natively is quite simple, just install steam from the arch repo and then you go. As long as the drivers are set up will then there shouldn’t be any issue and it should run flawlessly.
pacman -S steam
Follow the prompts
WINE
Wiki Wine link:
https://wiki.archlinux.org/index.php/Wine
Steam+Wine:
https://wiki.archlinux.org/index.php/Steam_on_Wine
Incomplete
Do NOT run wine in root.
acman -S wine winetricks wine_gecko wine-mono lib32-libxm12 lib32-mpg123 lib32-lcms2 lib32-giflib lib32-libpng playonlinux
winetricks allfonts
winecfg
WINEARCH=win32 WINEPREFIX=~/win32 winecfg
WINEARCH=win32 WINEPREFIX=~/win32 winetricks -q msxm13 dotnet40 allfonts
